Variable speed and forward and backward


When shifting into gear, first push the throttle handle forward to the low-speed idling position, and then push the main clutch lever to the forefront to separate the main clutch. Due to the action of the small brake in the main clutch, the power input shaft of the transmission stops rotating . At this time, you can correctly move the shift lever to the required gear, and then put the forward or retreat lever to the forward or backward position. After the gear is engaged, pull the throttle handle backward to increase the engine speed, and connect the main clutch smoothly, and the bulldozer starts to drive.


When the Bulldozer is driving, the main clutch control lever should be pulled to the rearmost position, not in the semi-engaged position. Because the half-engagement of the main clutch will aggravate the friction lining wear.


Bulldozer transmissions generally have 5 forward gears and 4 reverse gears. The advance and retreat rod can be used to change the direction of travel of the bulldozer.


When the bulldozer is in operation, it should run at the highest speed possible to improve the efficiency of the operation. However, the driver should always pay attention to whether the engine is running normally, and if the engine is overheated and the exhaust is emitting black smoke, the speed should be appropriately reduced.


Turn to


When the Track Type Dozer is turning during operation, the steering clutch lever of the steering can be pulled back to separate the steering clutch, so the speed of the crawler on the corresponding side slows down and the bulldozer starts to turn. If you want to make a sharp turn of the bulldozer, in addition to separating the steering clutch, you should also step on the corresponding brake pedal. Generally, sharp turns are allowed only when running in the first gear. When the brake is not in use, the foot should not be placed on the brake pedal, otherwise it will cause the brake belt to wear and increase fuel consumption.


When the bulldozer is turning, you should step on the brake pedal steadily to avoid jumping when turning. After the turn, the brake pedal should be released first, and then the joystick should be released. If the turning radius is large, there is no need to step on the brake pedal. When it is not necessary, avoid turning the bulldozer on the spot at high speed to avoid accidents caused by track derailment.


Hydrostatic Bulldozer

Hydrostatic Bulldozer


Ramp driving


Different types of bulldozers have different climbing abilities, and the slope and terrain that can be adapted to bulldozers of the same structure are different. The driver should be familiar with the climbing limit of the model used to avoid landslides due to insufficient up and downhill ability.


Before going uphill, you should choose a suitable gear according to the terrain, the size and length of the slope, and you are not allowed to change gears during the climb. When going uphill, the bulldozer should run at a vertical angle to the lateral direction of the mountain slope, and lateral driving is not allowed on steep slopes. The blade can be lowered appropriately so as not to affect the line of sight, and in the event of a landslide, the blade can be quickly landed on the ground to help the bulldozer brake.


If the engine stalls on the way uphill, stop the fuel supply immediately, lower the blade and brake urgently. When the machine cannot be stopped on a slope, it should be shifted to reverse gear and slowly slide to the bottom of the slope before starting. If the fuel supply is not stopped and the forward gear is slid down, the power will be transmitted back to the engine, which will cause reverse rotation and fire, causing the air filter to spray fuel outward. In case of fire in the reverse direction, you should quickly turn off the throttle and brake the bulldozer. Before restarting, check whether the shift lever is in the neutral position.


When the bulldozer is going downhill, low-speed gear and low throttle should be selected and the brake pedal should be used.


Through cliffs or rocky beaches


When bulldozers need to pass obstacles such as large soil packs or cliffs, they should drive up slowly at a low speed. When reaching the apex, the moment the fuselage is about to tilt forward, the clutch should be quickly disengaged, the front of the bulldozer should be slowly landed, and then the clutch should be engaged to continue forward. Do not drive obliquely over obstacles, and do not pull the steering lever when driving over obstacles.


When passing through a rocky beach, you must choose a route in advance, keep driving, make as little steering as possible on the way, and drive with low gear and low throttle. Driving and making sharp turns on bumpy rocky beach with high gear and high throttle are not allowed.
